Coin Cell Battery Constant Temperature Test Chamber

Coin Cell Battery Constant Temperature Test Chamber

Product Name;Constant Temperature Test Chamber
Model:AOT-MHW-200
Temperature range：0-60
Inner litre：200L
Product description: This constant temperature test chamber is mainly used for the temperature test of button batteries and 3C soft pack batteries. It has the characteristics of maximizing equipment space utilization and
INQUIRY

This constant temperature test chamber is mainly used for the temperature test of button batteries and 3C soft pack batteries. It has the characteristics of maximizing equipment space utilization and integrated operation of BTS host computer control. Mainly for research institutions, universities and battery production enterprise experimental centers.

The battery charge and discharge test system and the environmental test box, through the BTS host computer control system, realize integrated operation and work together to maximize the battery characteristics and functions.

Model	AOT-MHW-200
Model naming rule	①Temperature Chamber Series
	② Inner litre：200L
	③2：2 layers structure （ 1 layer not to display as default）
	④8T：8 temperature zones
	⑤Refrigeration mode: S:Semiconductor refrigeration （temperature range：15℃-60℃) Compressor refrigeration not to display as default （ temperature range：0℃-60℃）
	⑥110V：110VAC
Application	Constant temperature test of cylindrical batteries and 3C pouch cell batteries. Apply to electricians, electronics instrumentation, materials, semiconductors, etc. It is a reliability testing equipment for battery performance test by new energy enterprises and scientific research institutes.
Testing Material Limit	Strictly forbidden to test or storage in below situation: Inflammable, explosive and volatile materials Corrosive material Biological sample Strong electromagnetic emission source Radioactive substance Extremely toxic substance Anything that can produce above substance or material
Internal volume	200L<span style="font-family:" font-size:10.5pt;"="">
Internal dimension	W500 mm×D500 mm×H800 mm
Overall dimension	W600 mm×D700 mm×H1300 mm
Testing environmental condition	Ambient temperature:+25℃ Relative humidity≤85% No sample in the test box (No loading)
Temperature range	0～60℃
Temperature fluctuation	≤1℃ (No loading, stable temperature)
Temperature deviation	±2.0℃(No loading, stable temperature)
Heating time	25℃→60℃ ≤30 min
Cooling time	25℃→0℃ ≤50 min
