The importance of lithium battery separator

1、the basic function and working principle of lithium battery separator

Lithium battery diaphragm is located between the positive and negative poles of the battery, the main function is to prevent direct contact between the positive and negative poles leading to a short circuit, while allowing lithium ions to freely shuttle in the charging and discharging process. This seemingly simple task, in fact, the diaphragm's material, structure and performance puts forward very high requirements.

Preventing short circuit: The primary task of the diaphragm is to physically isolate the positive and negative electrodes to prevent short cir

cuit within the battery. Once the diaphragm breaks or fails, direct contact between the positive and negative electrodes will generate a large amount of heat, which may trigger a thermal runaway or even an explosion of the battery.

Ion conduction: Although the diaphragm needs to isolate the positive and negative electrodes, it must allow lithium ions to pass through. The conduction efficiency of lithium ions directly affects the charging and discharging rate and energy density of the battery. Efficient ionic conduction requires the diaphragm to have the proper porosity and pore size distribution to ensure the smooth passage of lithium ions.

Thermal and chemical stability: During battery charging and discharging, especially during fast charging and high power output, a large amount of heat is generated inside the battery. The diaphragm must be able to withstand high temperatures without deforming or melting, while remaining chemically stable to prevent reaction with the electrolyte.

Mechanical strength: the diaphragm needs to have a certain degree of mechanical strength to withstand the mechanical stress of the battery assembly and use process, to prevent breakage.

2、lithium battery separator performance requirements

In order to meet the above functions, lithiumbattery separator in the choice of materials, structural design and manufacturing process need to meet a series of strict standards.

Material selection: the current mainstream lithium battery separator materials mainly include polyethylene (PE), polypropylene (PP) and its composite materials. These materials have excellent chemical stability, thermal stability and mechanical strength, while the cost is relatively low. With the advancement of technology, some new materials such as ceramic-coated diaphragm and nanofiber diaphragm are also gradually entering the market, which further enhance the performance of the battery by improving the pore structure and thermal stability.

Porosity and pore size distribution: Ideal diaphragms should have high porosity (usually greater than 40%) to provide sufficient ion channels. At the same time, the pore size distribution should be uniform to avoid large holes that lead to short-circuit risk and small holes that may hinder ion conduction. Optimization of porosity and pore size distribution can be achieved through precise control of the manufacturing process.

Thickness and uniformity: The thickness of the diaphragm directly affects the bulk energy density and safety of the battery. Thinner diaphragm can reduce the weight and volume of the battery and increase the energy density, but too thin may lead to insufficient mechanical strength and increase the risk of breakage. Therefore, under the premise of ensuring mechanical strength, reducing the thickness of the diaphragm as much as possible is one of the directions of technology development. In addition, the uniformity of diaphragm thickness is crucial, which affects the consistency and cycle life of the battery.

Thermal shutdown performance: When the battery temperature rises abnormally, the diaphragm should be able to quickly close the pores at a certain temperature, preventing lithium ions from continuing conduction, thus cutting off the current and preventing the battery from thermal runaway. This feature is crucial for improving the safety of the battery.

3、lithium battery diaphragm technology innovation and development trend

Ceramic coated diaphragm: by coating a layer of ceramic particles (such as alumina, silica, etc.) on the surface of the polyolefin diaphragm, it can significantly improve the thermal stability and mechanical strength of the diaphragm, as well as improve the ionic conductivity. The ceramic coating can also effectively inhibit the growth of lithium dendrites, improving battery safety and cycle life.

Nanofiber diaphragm: Nanofiber diaphragms prepared using electrostatic spinning technology have extremely high porosity and specific surface area, which can provide more efficient ion conduction channels. In addition, nanofiber diaphragms exhibit excellent flexibility and mechanical strength, making them ideal for next-generation high-performance lithium batteries.

Solid electrolyte diaphragm: Solid electrolyte diaphragm is a major breakthrough in lithium battery technology, which completely replaces liquid electrolyte and fundamentally solves the battery leakage, combustion and other safety issues. Solid electrolyte diaphragm has higher energy density, longer cycle life and better safety, but is still facing challenges such as high cost and low ionic conduction efficiency.

Intelligent diaphragm: With the development of IoT and AI technology, intelligent diaphragm becomes possible. By embedding sensors or smart materials in the diaphragm, it can monitor the battery status in real time, warn potential safety risks in advance, and realize the intelligent management of the battery.

4、lithium battery diaphragm impact on the electric vehicle industry

As a key component of the battery, the performance of lithium battery diaphragm directly affects the electric vehicle range, safety, cost and market competitiveness.

Enhance the range: High-performance diaphragm can significantly improve the ionic conduction efficiency of the battery, thereby increasing the usable capacity of the battery and extending the range of electric vehicles. This is important for easing consumers' range anxiety and promoting the popularization of electric vehicles.

Enhanced safety: The thermal stability and thermal shutdown performance of the diaphragm is an important guarantee of battery safety. In case of battery abnormality, the diaphragm can respond quickly to cut off the current, preventing the battery from thermal runaway and explosion, and protecting the safety of the occupants.

Cost reduction: Through technological innovation and large-scale production, the manufacturing cost of diaphragm can be reduced, which in turn reduces the overall cost of the battery. This is crucial to improving the market competitiveness of electric vehicles and accelerating the commercialization of the electric vehicle industry.

5、Conclusion

The importance of lithium battery diaphragm as the key guardian of the heart of electric vehicles cannot be ignored. Through material innovation, structural optimization and improvement of manufacturing process, the performance of diaphragm has been continuously improved, providing strong support for the range, safety and cost optimization of electric vehicles. In the future, with the breakthrough of solid electrolyte diaphragm, intelligent diaphragm and other technologies, lithium battery diaphragm will play a more important role in the electric vehicle industry, and promote the electric vehicle industry to a higher level of development.
